Technical Specifications
Torque
Max torque in forward :- 1.6 Nm
Min torque in forward :- 0.5 Nm
Torque Control System :- Shut-off-pneumatic valve
Design & Functions
Adjustment :- Key
Body :- Aluminum
Clutch housing :- Steel
Clutch Type :- Ball clutch
Handle type :- Pistol
Main Material type :- Aluminium
Output drive size (in) :- 1/4
Output drive type :- Hex
Output retainer type :- Quick change
Reversible :- Yes
Starting system :- Lever
Speed
Free Speed :- 1500 rpm
Air consumption at free speed :- 6 l/s
Air information
Air inlet thread size (in) :- 1/4
Air inlet thread type :- BSP
Max dynamic air working pressure :- 6.3 bar
Min hose diam (16 ft hose length) :- 0.31 in
Min hose diam (5 m hose length) :- 8 mm
Size & Weight
Height (H) :- 28 mm
Length (L) :- 222 mm
Width (W) :- 28 mm
Weight :- 0.9 kg
Noise & vibrations
Sound Pressure :- 73 dB(A)
Vibration (m/s²) :- <2.5
Benefits
- Accurate and durable shut-off clutch for various fastening
- Low noise level
- Robust aluminum body, even for heavy duty applications
- Convenient progressive trigger and one-hand reverse button for ergonomic handling
