Technical Specifications
Speed
Free Speed :- 280 rpm
Torque
Max working torque reverse :- 25 Nm
Max torque reverse :- 35 Nm
Min working torque reverse :- 5 Nm
Size & Weight
Height (H) :- 37 mm
Length (L) :- 169 mm
Width (W) :- 38 mm
Side to Center :- 19 mm
Weight :- 0.5 kg
General
Subfamily :- Pneumatic Ratchet Wrenches
Noise & vibrations
Sound Power :- 93 dB(A)
Sound Pressure :- 82 dB(A)
Uncertainty vibration-K :- 1.5 m/s²
Vibration (m/s²) :- 4
Air information
Air consumption at load :- 5.1 l/s
Air inlet thread size (in) :- 1/4
Max dynamic air working pressure :- 6.3 bar
Min hose diam (5 m hose length) :- 10 mm
Design & Functions
Main Material type :- Composite
Output drive size (in) :- 3/8
Output drive type :- Sq
Output retainer type :- Ball detent
Starting system :- Lever
Benefits
- Comfortable ultra-compact (6.6 in/169mm long), lightweight (1.1 lbs/0.5 kg) tool that allows ease of access in hard-to-reach areas
- Aluminium body with insulating composite housing and head composite protective cover supplied with the tool
- Short and wide teasing lever to better adjust torque with 280 rpm
- Back exhaust avoids blowing dirt and dust
- New power easy-to-use regulator to regulate speed from zero to maximum
