Technical Specifications
Torque
Max working torque fwd :- 400 Nm
Max torque reverse :- 550 Nm
Min working torque fwd :- 80 Nm
Torque limited :- No
Air information
Air consumption at load (Normo) :- 21.2 1/sNl
Air consumption at load :- 10 l/s
Air inlet thread size (in) :- 1/4
Max dynamic air working pressure :- 6.3 bar
Min hose diam (16 ft hose length) :- 0.38 in
Min hose diam (5 m hose length) :- 10 mm
Noise & vibrations
Sound Power :- 100 dB(A)
Sound Pressure :- 89 dB(A)
Uncertainty vibration-K :- 3.2 m/s²
Vibration (m/s²) :- 6.6
Speed
Free Speed :- 11500 rpm
Size & Weight
Length (L) :- 177 mm
Power weight ratio :- 450 Nm/kg
Side to Center :- 30 mm
Weight :- 1.2 kg
Design & Functions
Blow per minute :- 1250
Body :- Composite
Clutch housing :- Aluminium
Clutch lubrication type :- Grease
Handle type :- Pistol
Impact mecanism :- Twin hammer
Main Material type :- Composite
Output drive size (in) :- 1/2
Output drive type :- Sq
Output retainer type :- Friction ring
Starting system :- Trigger
Suspension option :- Included
Benefits
- The twin hammer clutch mechanism offers a high power/weight ratio.
- Low vibration sensation for operator comfort, even at very high torque.
- Lightweight composite body and aluminium clutch housing
- 3 power settings ensure high progressive maximum torque for smooth operation.
- Integrated suspension bail for use with balancer
