Technical Specifications
Torque
Max working torque fwd :- 2800 Nm
Max torque reverse :- 3390 Nm
Min working torque fwd :- 240 Nm
Torque limited :- No
Air information
Air consumption at load :- 25 l/s
Air inlet thread size (in) :- 1/2
Max dynamic air working pressure :- 6.3 bar
Min hose diam (16 ft hose length) :- 0.5 in
Min hose diam (5 m hose length) :- 13 mm
Noise & vibrations
Sound Power :- 114 dB(A)
Sound Pressure :- 103 dB(A)
Uncertainty vibration-K :- 2.6 m/s²
Vibration (m/s²) :- 8.5
Speed
Free Speed :- 3700 rpm
Size & Weight
Length (L) :- 572 mm
Power weight ratio :- 200 Nm/kg
Weight :- 16.2 kg
Design & Functions
Blow per minute :- 540
Body :- Aluminium
Clutch housing :- Steel
Clutch lubrication type :- Grease
Handle type :- D-handle
Impact mecanism :- Pinless rocking dog
Main Material type :- Aluminium
Output drive size (in) :- 1
Output drive type :- Sq
Output retainer type :- Dual
Side handle :- Yes
Starting system :- Trigger
Benefits
- Outstanding operator productivity for high volume tire work on trucks, buses, and heavy equipment.
- Metal motor housing with rocking dog hammer mechanism for high durability
- Convenient reverse valve with 4-position power settings for ease of use
