Technical Specifications
Torque
Max working torque fwd :- 1290 Nm
Max torque reverse :- 1630 Nm
Min working torque fwd :- 350 Nm
Torque limited :- No
Air information
Air inlet thread size (in) :- 3/8
Max dynamic air working pressure :- 6.3 bar
Min hose diam (16 ft hose length) :- 0.5 in
Min hose diam (5 m hose length) :- 13 mm
Noise & vibrations
Sound Power :- 107 dB(A)
Sound Pressure :- 96 dB(A)
Uncertainty vibration-K :- 1.3 m/s²
Vibration (m/s²) :- 9.4
Speed
Free Speed :- 6300 rpm
Size & Weight
Length (L) :- 222 mm
Power weight ratio :- 290 Nm/kg
Side to Center :- 41 mm
Weight :- 5.5 kg
Design & Functions
Blow per minute :- 900
Body :- Aluminium
Clutch housing :- Steel
Clutch lubrication type :- Oil bath
Handle type :- Pistol
Impact mecanism :- Twin hammer
Output drive size (in) :- 3/4
Output drive type :- Sq
Output retainer type :- Friction ring
Starting system :- Trigger
Benefits
- Powerful hard hitting twin hammer clutch mechanism
- Flexibility and safety is guaranteed with the double hole and ring retaining system.
- Steel clutch housing and aluminium motor housing for robustness
- Short and narrow side-to-centre for easy access
