Technical Specifications
Torque
Max working torque fwd :- 575 Nm
Max torque reverse :- 1300 Nm
Min working torque fwd :- 80 Nm
Torque limited :- No
Air information
Air inlet thread size (in) :- 1/2
Max dynamic air working pressure :- 6.3 bar
Min hose diam (16 ft hose length) :- 0.38 in
Min hose diam (5 m hose length) :- 10 mm
Noise & vibrations
Sound Power :- 105 dB(A)
Sound Pressure :- 94 dB(A)
Uncertainty vibration-K :- 3.4 m/s²
Speed
Free Speed :- 7700 rpm
Air consumption at free speed :- 2.6 l/s
Size & Weight
Height (H) :- 205 mm
Length (L) :- 169 mm
Width (W) :- 76 mm
Power weight ratio :- 670 Nm/kg
Side to Center :- 38 mm
Weight :- 1.93 kg
Design & Functions
Blow per minute :- 1200
Body :- Composite
Handle type :- Pistol
Impact mecanism :- Twin hammer
Output drive size (in) :- 1/2
Output drive type :- Sq
Output retainer type :- Friction ring
Starting system :- Trigger
Benefits
- Unique multi-position power control system: 11 setting options
- Patented Air Flex Mini air inlet: 360° swivel air inlet for freedom of movement
- Twin hammer impact mechanism, hard chromium aluminium cylinder, and bumpers all around the tool for high durability
- Due to its composite motor housing, the tool is compact and lightweight
