Model Specifications
|
Model |
Shank Opening |
Blows per Minute |
Bore Diameter (in) |
Bore Diameter (mm) |
Stroke Length (in) |
Stroke Length (mm) |
Tool Weight (lbs) |
Tool Weight (kg) |
Overall Length (in) |
Overall Length (mm) |
Average Air Consumption (cfm) |
Average Air Consumption (L/min) |
Air Consumption @ Load (cfm) |
Air Consumption @ Load (L/min) |
Sound Pressure/Power (dBA) |
Vibration m/s2 (uncertainty K) |
Air Inlet NPTF (in) |
Min. Hose Size (in) |
Min. Hose Size (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
117 |
Round |
2000 |
0.69 |
17 |
3.5 |
89 |
4.1 |
1.86 |
9.9 |
251 |
3 |
85 |
14 |
396 |
103.5 / 116.5 |
9.2 (uncertainty: 3.0) |
1/4 |
3/8 |
10 |
