Shakti Technology MMA-200G Inverter ARC Compact Welding Machine

MMA 200G

Shakti Technology MMA-200G Inverter ARC Compact Welding Machine (IGBT) 200A with Hot Start and Anti-Stick Functions

Suitable for 3.15 mm to 1.5 mm welding electrode. | Advanced IGBT inverter technology, hot start ,excellent arc stability, eliminate the electrode sticking at arc start. Most recommend welder. | Its over-voltage protection, under voltage protection, over current protection, over load protection designs ensure you are safe when you use it. Multipurpose -This Machine is suitable for welding mild steel, stainless steel and other kinds of metal; It is great for welding, maintenance, repair, Heavy and light industry and more | Convenient Yet Safe – This inverter has the ability to be plugged into a 220V wall socket with household current instead of high voltage and also can be connected with Gensets

Technical Specification

  • Input Voltage : 220V
  • Frequency : 50/60 Hz
  • Input Current : 33 Amps
  • No Load Voltage : 45 V
  • Duty Cycle : 60%@ 200A
  • Efficiency : 85%
  • Generator Required : 5.8 Kw
  • Protection Class : IP21S
  • Brand : ‎Shakti Technology
  • Country of Origin : China
  • Model number : ‎MMA 200G

Item Dimensions

  • Product Net Weight : 6kg
  • Product Gross Weight : 7kg
  • Packing Size : 29x15x25cm
