Technical Specifications
Speed
Free Speed :- 220 rpm
Torque
Max working torque reverse :- 17 Nm
Max torque reverse :- 17 Nm
Min working torque reverse :- 5 Nm
Size & Weight
Length (L) :- 197 mm
Weight :- 0.51 kg
General
Subfamily :- Pneumatic Ratchet Wrenches
Noise & vibrations
Sound Power :- 102 dB(A)
Sound Pressure :- 91 dB(A)
Uncertainty vibration-K :- 2 m/s²
Vibration (m/s²) :- 4.1
Air information
Air consumption at load :- 7 l/s
Air inlet thread size (in) :- 1/4
Max dynamic air working pressure :- 6.3 bar
Min hose diam (5 m hose length) :- 10 mm
Design & Functions
Main Material type :- Aluminum
Output drive size (in) :- 1/4
Output drive type :- Sq
Output retainer type :- Ball detent
Starting system :- Lever
Benefits
- Extended length (7.75in / 197mm long) for ease of access in hard to reach places
- Lightweight tool (1.13 lbs. / 0.51 kg) for improved comfort
