Features
Reliability:
- Built with a steel hammer case and metal housing, this wrench can withstand repeated drops and harsh weather conditions.
Reach:
- Thanks to multiple retention methods, the 285B Series Impact Wrench lets you access hard-to-reach spaces, while maintaining a strong connection to the socket.
Power:
- The rocking dog’s combination of high inertia and and low BPM means this tool can deliver a powerful blow with little air, giving you all the power you want without having to overextend yourself.
Other Features:
- Designed for the professional with over 1475 ft-lbs of torque for the toughest applications
- New phenolic vanes resist harsh environments for less downtime on the job
- Protective Rubber Tool Boot for all models of this air impact wrench
- Durable design for handling the toughest jobs
- Improved feather-touch trigger enables impressive control of the air impact wrench
- Optimized for the vehicle repair industry, heavy trucks, tire lanes, and MRO
- 1-year warranty
Model Specifications
| Model | Configuration | Actuation | Drive Size | Drive Type | Forward Torque (ft-lbs) | Forward Torque (Nm) | Max Reverse Torque (ft-lbs) | Max Reverse Torque (Nm) | Blows per minute | Free Speed (RPM) | Impacting Sound Level dB(A) — ISO15744 (pressure/power) | Free Speed Sound Level dB(A) — CAGI/ANSI S12.41 (pressure/power) | Vibration Level m/s² (K) | Weight (lbs) | Weight (kg) | Width (in) | Width (mm) | Height (in) | Height (mm) | Length (in) | Length (mm) | Air Inlet | Min Hose Size (in) | Min Hose Size (mm) | Air Consumption @ Load (cfm) | Air Consumption @ Load (L/min) | Average Air Consumption (cfm) | Average Air Consumption (L/min) | PSI | Bar |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 285B | D-Handle | Inside Trigger | 1 in. | Square, Hog-Ring and Thru-Hole | 1475 | 2000 | 1475 | 2000 | 700 | 5250 | 98.8 / 109.8 | 103.4 / 114.4 | 8 (1.2) | 24.6 | 11.16 | 8.1 | 206 | 7.2 | 182 | 14.2 | 361 | 1/2 in. | 3/4 | 19 | 46 | 1303 | 11 | 312 | 90 | 6.2 |
| 285B-6 | D-Handle | Inside Trigger | 1 in. | Square, Hog-Ring and Thru-Hole, 6 in. Ext | 1475 | 2000 | 1475 | 2000 | 700 | 5250 | 98.8 / 109.8 | 103.4 / 114.4 | 9 (2.7) | 27.8 | 12.61 | 8.1 | 206 | 7.2 | 182 | 20.4 | 519 | 1/2 in. | 3/4 | 19 | 46 | 1303 | 11 | 312 | 90 | 6.2 |
