Features
Tool Design
- Variable speed control allows slow starting and high speed for fast drilling
- Excellent power-to-weight ratio gets the job done with less fatigue
- Speeds to 5100 RPM
- Maximum TIR of .005′ ensures precision holes for critical applications.
| Model | Actuation | Reversible | Max. Working Torque (Nm) | Max. Working Torque (in-lb) | Free Speed (rpm) | Weight with Chuck (kg) | Weight with Chuck (lb) | Length with Chuck (mm) | Length with Chuck (in) | Bit Holder Capacity (in) | Bit Holder Capacity (mm) | Side to Center (mm) | Side to Center (in) | Sound Level dB(A) | Rated Power (hp) | Air Inlet | cfm |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| QS151D | Lever Start | No | 3.8 | 33.6 | 1500 | 0.6 | 1.4 | 205 | 8.1 | 1/4 | 6 | 15 | 0.6 | 75 | 0.25 | 1/4 in. NPT | 16 |
| QS301D | Lever Start | No | 1.9 | 16.8 | 3000 | 0.6 | 1.4 | 205 | 8.1 | 1/4 | 6 | 15 | 0.6 | 75 | 0.25 | 1/4 in. NPT | 16 |
| QS381D | Lever Start | No |
|
|
3800 | 0.62 | 1.37 | 205 | 8.07 | 1/4 | 6.35 | 15 | 0.6 | 75 | 0.25 | 1/4 in. NPT | 16 |
| QS511D | Lever Start | No | 1.2 | 10.6 | 5100 | 0.6 | 1.4 | 205 | 8.1 | 1/4 | 6 | 15 | 0.6 | 75 | 0.25 | 1/4 in. NPT | 16 |
