Model Specifications
|
Model |
Actuation |
Reversible |
Max. Working Torque (Nm) |
Max. Working Torque (in-lb) |
Free Speed (rpm) |
Weight with Chuck (kg) |
Weight with Chuck (lb) |
Length with Chuck (mm) |
Length with Chuck (in) |
Bit Holder Capacity (in) |
Bit Holder Capacity (mm) |
Angle Head Heights w/ Chuck (mm) |
Angle Head Heights w/ Chuck (in) |
Side to Center (mm) |
Side to Center (in) |
Sound Level dB(A) |
Rated Power (hp) |
Head Style |
Air Inlet |
cfm |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
6LH1A1 |
Lever Start |
No |
|
|
6000 |
0.95 |
2.13 |
246 |
9.69 |
1/4 in.- 28 Female Thread |
N/A |
|
|
|
|
|
0.51 |
90 Degree Small Head |
1/4 in. NPT |
20 |
|
6LJ1A1 |
Lever Start |
No |
|
|
5100 |
0.95 |
2.13 |
246 |
9.69 |
1/4 in.- 28 Female Thread |
N/A |
|
|
|
|
|
0.51 |
90 Degree Small Head |
1/4 in. NPT |
20 |
|
6LJJ1A1 |
Lever Start |
No |
|
|
3950 |
0.95 |
2.13 |
246 |
9.69 |
1/4 in.- 28 Female Thread |
N/A |
|
|
|
|
|
0.51 |
90 Degree Small Head |
1/4 in. NPT |
20 |
|
6LK1A1 |
Lever Start |
No |
|
|
3100 |
0.95 |
2.13 |
246 |
9.69 |
1/4 in.- 28 Female Thread |
N/A |
|
|
|
|
|
0.51 |
90 Degree Small Head |
1/4 in. NPT |
20 |
|
6LK2A41 |
Lever Start |
No |
7.3 |
64.6 |
2000 |
1.3 |
2.8 |
241 |
9.5 |
1/4 |
6 |
75 |
3 |
14 |
0.5 |
74 |
0.51 |
90 Degree Chuck |
1/4 in. NPT |
20 |
|
6LR3A44 |
Lever Start |
No |
36.2 |
320.4 |
400 |
1.8 |
4 |
272 |
10.7 |
1/2 |
13 |
105 |
4.1 |
18 |
0.7 |
74 |
0.51 |
90 Degree Chuck |
1/4 in. NPT |
20 |
