Features
- This series is compact, well-balanced and lightweight, and has an egg-shaped housing designed for a natural fit and maximum operator comfort.
Speed:
- This tool’s high speed allows you to finish any job quickly and easily.
Durable:
- These screwdrivers will perform cycle after cycle. They’re tools you can trust.
Performance:
- With the speed, accuracy and reliability of these screwdrivers, you’ll be able to work without worrying about your end product.
|
Model |
Actuation |
Torque Range (Nm) |
Torque Range (in-lbs) |
Free Speed (rpm) |
Weight (kg) |
Weight (lb.) |
Length (mm) |
Length (in) |
Side to Center Distance (mm) |
Side to Center Distance (in) |
Spindle Type |
Sound Level dB(A) @ Free Speed |
Inlet Location |
Air Inlet (NPTF/NPT) |
CFM |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
QP1S05C1TD |
Trigger Start |
0.3 – 5.4 |
3.0 – 47.8 |
500 |
0.8 |
1.9 |
223 |
8.8 |
15 |
0.6 |
1/4 in. Hex Quick Change |
75 |
Top |
1/4 in. NPT |
16 |
|
QP1S10C1TD |
Trigger Start |
0.3 – 4.5 |
3.0 – 40.0 |
1000 |
0.8 |
1.9 |
223 |
8.8 |
15 |
0.6 |
1/4 in. Hex Quick Change |
75 |
Top |
1/4 in. NPT |
16 |
|
QP1T10C1TD |
Trigger + Push to Start |
0.3 – 4.5 |
3.0 – 40.0 |
1000 |
0.8 |
1.9 |
223 |
8.8 |
15 |
0.6 |
1/4 in. Hex Quick Change |
75 |
Top |
1/4 in. NPT |
16 |
|
QP1T15C1TD |
Trigger + Push to Start |
0.3 – 3.1 |
3.0 – 27.4 |
1500 |
0.8 |
1.9 |
223 |
8.8 |
15 |
0.6 |
1/4 in. Hex Quick Change |
75 |
Top |
1/4 in. NPT |
16 |
|
QP1S15C1TD |
Trigger Start |
0.3 – 3.1 |
3.0 – 27.4 |
1500 |
0.8 |
1.9 |
223 |
8.8 |
15 |
0.6 |
1/4 in. Hex Quick Change |
75 |
Top |
1/4 in. NPT |
16 |
