Technical Specifications
Torque
Max working torque fwd :- 1220 Nm
Max torque reverse :- 1490 Nm
Min working torque fwd :- 270 Nm
Torque limited :- No
Air information
Air inlet thread size (in) :- 3/8
Max dynamic air working pressure :- 6.3 bar
Min hose diam (16 ft hose length) :- 0.5 in
Min hose diam (5 m hose length) :- 13 mm
Noise & vibrations
Sound Power :- 103 dB(A)
Sound Pressure :- 92 dB(A)
Uncertainty vibration-K :- 4.1 m/s²
Vibration (m/s²) :- 13.9
Speed
Free Speed :- 4000 rpm
Air consumption at free speed :- 35 l/s
Size & Weight
Length (L) :- 222 mm
Power weight ratio :- 280 Nm/kg
Side to Center :- 37 mm
Weight :- 5.3 kg
Design & Functions
Blow per minute :- 1100
Body :- Aluminium
Clutch housing :- Steel
Clutch lubrication type :- Grease
Handle type :- Pistol
Impact mecanism :- 2-jaws
Main Material type :- Aluminium
Output drive size (in) :- 3/4
Output drive type :- Sq
Output retainer type :- Friction ring
Starting system :- Trigger
Benefits
- A very compact design to meet applications in very tight environments
- Reliable 2-jaw clutch mechanism for hard and soft joint application
- Low vibration feeling for operator comfort even at very high torque.
- Aluminium body and robust steel clutch housing provides enhanced durability
- Hole type socket retainer with O-ring for safety
