Technical Specifications
Torque
Max working torque fwd :- 2440 Nm
Max torque reverse :- 3790 Nm
Min working torque fwd :- 1220 Nm
Torque limited :- No
Air information
Air inlet thread size (in) :- 1/2
Max dynamic air working pressure :- 6.3 bar
Min hose diam (16 ft hose length) :- 1 in
Min hose diam (5 m hose length) :- 16 mm
Noise & vibrations
Sound Power :- 110 dB(A)
Sound Pressure :- 99 dB(A)
Uncertainty vibration-K :- 4.1 m/s²
Vibration (m/s²) :- 18
Speed
Free Speed :- 3500 rpm
Air consumption at free speed :- 55 l/s
Size & Weight
Length (L) :- 360 mm
Power weight ratio :- 360 Nm/kg
Side to Center :- 46 mm
Weight :- 10.4 kg
Design & Functions
Blow per minute :- 1020
Body :- Aluminium
Clutch housing :- Steel
Clutch lubrication type :- Grease
Handle type :- D-handle
Impact mecanism :- 2-jaws
Main Material type :- Aluminium
Output drive size (in) :- 1
Output drive type :- Sq
Output retainer type :- Hole
Side handle :- Yes
Starting system :- Trigger
Benefits
- Reliable 2 jaws clutch mechanism for hard and soft joint applications
- Durable lightweight aluminium body
- Robust steel clutch housing for extreme durability
- 2-jaw clutch ensures progressive torque increase for high torque bolt disassembly applications with minimal vibration
- 360° rotatable side handle offers excellent grip for all applications
