Technical Specifications
Torque
Max working torque fwd :- 224 Nm
Max torque reverse :- 300 Nm
Min working torque fwd :- 34 Nm
Torque limited :- No
Air information
Air consumption at load :- 7.5 l/s
Air inlet thread size (in) :- 1/4
Max dynamic air working pressure :- 6.3 bar
Min hose diam (16 ft hose length) :- 0.38 in
Min hose diam (5 m hose length) :- 10 mm
Noise & vibrations
Sound Power :- 104 dB(A)
Sound Pressure :- 93 dB(A)
Uncertainty vibration-K :- 1.3 m/s²
Vibration (m/s²) :- 10.3
Speed
Free Speed :- 9000 rpm
Air consumption at free speed :- 11 l/s
Size & Weight
Length (L) :- 240 mm
Side to Center :- 30 mm
Weight :- 1.13 k
Design & Functions
Blow per minute :- 1600
Body :- Aluminum
Clutch housing :- Aluminum
Clutch lubrication type :- Grease
Handle type :- Pistol
Impact mecanism :- Single hammer
Main Material type :- Aluminium
Output drive size (in) :- 1/2
Output drive type :- Sq
Output retainer type :- Friction ring
Starting system :- Trigger
Benefits
- A compact tool with direct drive transmission mechanism for tight applications
- Single handed Forward – Reverse operation with 3 power settings in forward and 1 in reverse
- Over moulded composite and ergonomically designed handle to fit the hand perfectly and offer better comfort
- Metal housing, jumbo hammer impact mechanism, and steel motor for high durability
- Full teasing trigger for better control
