Model Specifications
|
Model |
Actuation |
Reversible |
Max. Working Torque (Nm) |
Max. Working Torque (in-lb) |
Free Speed (rpm) |
Weight with Chuck (kg) |
Weight with Chuck (lb) |
Length with Chuck (mm) |
Length with Chuck (in) |
Bit Holder Capacity (in) |
Bit Holder Capacity (mm) |
Angle Head Heights w/ Collet (mm) |
Angle Head Heights w/ Chuck (mm) |
Angle Head Heights w/ Collet (in) |
Angle Head Heights w/ Chuck (in) |
Side to Center (mm) |
Side to Center (in) |
Sound Level dB(A) |
Rated Power (hp) |
Head Style |
Air Inlet |
cfm |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
7LM3A43 |
Lever Start |
No |
18.7 |
170 |
900 |
1.8 |
3.9 |
281 |
11.1 |
3/8 |
10 |
N/A |
99 |
N/A |
3.9 |
18 |
0.7 |
82 |
0.75 |
90 Degree Chuck |
1/4 in. NPT |
26 |
|
7LN3A44 |
Lever Start |
No |
28.1 |
255 |
600 |
1.9 |
4.2 |
281 |
11.1 |
1/2 |
13 |
N/A |
105 |
N/A |
4.1 |
18 |
0.7 |
82 |
0.75 |
90 Degree Chuck |
1/4 in. NPT |
26 |
