Technical Specifications
Torque
Max working torque fwd :- 2000 Nm
Max torque reverse :- 2600 Nm
Min working torque fwd :- 500 Nm
Torque limited :- No
Air information
Air consumption at load :- 19 l/s
Air inlet thread size (in) :- 1/2
Max dynamic air working pressure :- 6.3 bar
Min hose diam (16 ft hose length) :- 0.5 in
Min hose diam (5 m hose length) :- 13 mm
Noise & vibrations
Sound Power :- 111 dB(A)
Sound Pressure :- 100 dB(A)
Uncertainty vibration-K :- 1.8 m/s²
Vibration (m/s²) :- 7.8
Speed
Free Speed :- 5200 rpm
Size & Weight
Length (L) :- 570 mm
Power weight ratio :- 250 Nm/kg
Weight :- 11.6 kg
Design & Functions
Blow per minute :- 500
Body :- Aluminium
Clutch housing :- Aluminium
Clutch lubrication type :- Grease
Handle type :- D-handle
Impact mecanism :- Pinless rocking dog
Main Material type :- Aluminium
Output drive size (in) :- #5 Spline
Output drive type :- #5 Spline
Output retainer type :- Friction ring
Side handle :- Yes
Starting system :- Trigger
Benefits
- 1,920 ft.lbs ( 2,600 Nm) of max torque in reverse position for high productivity
- Metal housing and pinless closed reinforced rocking dog impact mechanism for high durability
- Power control regulators at the rear of the unit with 3 reverse and 3 forward positions
- Integrated protective cover on the clutch housing protects both applications & tool
- Low vibration for improved comfort
