Technical Specifications
Speed
Free Speed :- 270 rpm
Torque
Max working torque reverse :- 35 Nm
Max torque reverse :- 35 Nm
Min working torque reverse :- 7 Nm
Size & Weight
Length (L) :- 128 mm
Weight :- 0.49 kg
General
Subfamily :- Pneumatic Ratchet Wrenches
Noise & vibrations
Sound Power :- 93 dB(A)
Sound Pressure :- 82 dB(A)
Uncertainty vibration-K :- 1.5 m/s²
Vibration (m/s²) :- 5
Air information
Air consumption at load :- 5.6 l/s
Air inlet thread size (in) :- 1/4
Air inlet thread type :- NPTF
Max dynamic air working pressure :- 6.3 bar
Min hose diam (5 m hose length) :- 10 mm
Design & Functions
Main Material type :- Composite
Output drive size (in) :- 1/4
Output drive type :- Sq
Output retainer type :- Quick release
Starting system :- Lever
Benefits
- High power (27 ft.lbs / 35 Nm) for better productivity
- Extremely compact tool (5.1″ / 130 mm) that enables improved comfort and access in hard to reach places
