M2 Series Die Grinders

The M2-Series industrial Grinders is offering high durability with a powerful motor and less maintenance, more productivity with the speed governor helping to maximize life time of the abrasive, an adjustable guard and a spindle lock feature. It also offers versatility with the different configurations and speed rating covered by the range. For sure with the M2-Series from Ingersoll Rand you will get more time to work and less time in maintenance.

Features

Power:

  • The power-to-weight ratio on the M2 Series Die Grinders will help you tackle the biggest jobs.

Comfort:

  • An ergonomic body and lightweight composite housing increase the M2 Series’ ease-of-use.

Access:

  • Coming in straight, angle and extended configurations, the M2 Series Die Grinders give you easier access to hard-to-reach places.

Other Features:

  • Lube-free, 0.75 kW high performance motors run cooler and longer for less maintenance and faster material removal – Suited for heavier-duty grinding, cutting, cleaning, and polishing applications
  • Speed-governed motors on this die grinder help maximize the life of abrasives, increasing grinder efficiency and improving productivity
  • Quick-change spindle-lock eliminates the need for additional tools
  • Optimized for general industrial use, MRO, rail, heavy machinery, oil and gas, shipbuilding, construction, aerospace, and metal fabrication
  • Motor controller prevents over-speeding and manages airflow for efficient use



Categories: , Brand:

Model Specifications

Model

Rated Power (hp)

Rated Power (kW)

Max Free Speed (rpm)

Output

Wheel Type

Weight (lbs)

Weight (kg)

Length (in)

Length (mm)

Air Consumption @ Free Speed (cfm)

Air Consumption @ Free Speed (L/min)

Exhaust

M2A120RG4

1

0.75

12000

Collet (1/4 in. and 6 mm)

Burr

3.56

1.62

8.94

227

17

481

Rear

M2A180RG4

1

0.75

18000

Collet (1/4 in. and 6 mm)

Burr

3.56

1.62

8.94

227

25

708

Rear

M2H180RG4

1

0.75

18000

Collet (1/4 in. and 6 mm)

Burr

1.69

0.77

8.38

213

14

396

Rear

M2H200RG4

1

0.75

20000

Collet (1/4 in. and 6 mm)

Burr

1.69

0.77

8.38

213

17

481

Rear

M2H250RG4

1

0.75

25000

Collet (1/4 in. and 6 mm)

Burr

1.69

0.77

8.38

213

25

708

Rear

M2X075RG4

1

0.75

7500

Collet (1/4 in. and 6 mm)

Sanding Drum (Mounted)

2.97

1.35

11.95

304

25

708

Rear

M2X180RG4

1

0.75

18000

Collet (1/4 in. and 6 mm)

Burr

2.68

1.22

13.08

332

14

396

Rear

M2X200RG4

1

0.75

20000

Collet (1/4 in. and 6 mm)

Burr

2.68

1.22

13.08

332

17

481

Rear

M2X250RG4

1

0.75

25000

Collet (1/4 in. and 6 mm)

Burr

2.68

1.22

13.08

332

25

708

Rear
