Technical Specifications
Torque
Max working torque fwd :- 1250 Nm
Max torque reverse :- 1650 Nm
Min working torque fwd :- 250 Nm
Torque limited :- No
Air information
Air inlet thread size (in) :- 3/8
Max dynamic air working pressure :- 6.3 bar
Min hose diam (16 ft hose length) :- 0.5 in
Min hose diam (5 m hose length) :- 13 mm
Noise & vibrations
Sound Power :- 107 dB(A)
Sound Pressure :- 96 dB(A)
Uncertainty vibration-K :- 6.8 m/s²
Vibration (m/s²) :- 15.5
Speed
Free Speed :- 6500 rpm
Size & Weight
Length (L) :- 230 mm
Power weight ratio :- 500 Nm/kg
Side to Center :- 40 mm
Weight :- 3.65 kg
Design & Functions
Blow per minute :- 1000
Body :- Composite
Clutch housing :- Aluminium
Clutch lubrication type :- Grease
Handle type :- Pistol
Impact mecanism :- Twin hammer
Main Material type :- Composite
Output drive size (in) :- 3/4
Output drive type :- Sq
Output retainer type :- Dual
Starting system :- Trigger
Suspension option :- Optional
Benefits
- The twin hammer clutch mechanism offers a high power/weight ratio.
- Low vibration sensation for operator comfort, even at very high torque.
- Lightweight composite body and aluminium clutch housing
- 3 power settings ensure high progressive maximum torque for smooth operation.
- Integrated suspension bail for use with balancer
