CP0611P RLS #5 D-HANDLE PNEUMATIC IMPACT WRENCH
,

CP0611P RLS #5 D-HANDLE PNEUMATIC IMPACT WRENCH



The CP0611 is a robust and efficient 1″/ #5 impact wrench, designed with a 2-jaw clutch mechanism, aluminium body and steel clutch housing. Delivers reverse torque up to 3,790 Nm / 2,800 ft.lb. The CP0611 is built to operate comfortably in the most demanding industrial environments for hard or soft assembly/disassembly applications. The CP0611 Series is available in 4 models: Pistol or straight D-handles with hole or spline socket attachment options.Country of origin is JP. Customs tariff is 84671190

Categories: , Brand:

Technical Specifications

Torque
Max working torque fwd :- 2440 Nm
Max torque reverse :- 3790 Nm
Min working torque fwd :- 1.22 Nm
Torque limited :- No
Air information
Air inlet thread size (in) :- 1/2
Max dynamic air working pressure :- 6.3 bar
Min hose diam (5 m hose length) :- 13 mm
Noise & vibrations
Sound Power :- 113 dB(A)
Sound Pressure :- 102 dB(A)
Uncertainty vibration-K :- 4.7 m/s²
Vibration (m/s²) :- 16.8
Speed
Free Speed :- 3500 rpm
Size & Weight
Length (L) :- 272 mm
Power weight ratio :- 360 Nm/kg
Side to Center :- 46 mm
Weight :- 10.5 kg
Design & Functions
Blow per minute :- 1020
Body :- Aluminium
Clutch housing :- Steel
Clutch lubrication type :- Grease
Handle type :- Pistol
Impact mecanism :- 2-jaws
Main Material type :- Aluminium
Output drive size (in) :- #5 Spline
Output drive type :- #5 Spline
Output retainer type :- Pin retainer
Side handle :- Yes
Starting system :- Trigger

Benefits

  • Reliable 2 jaws clutch mechanism for hard and soft joint applications
  • Durable lightweight aluminium body
  • Robust steel clutch housing for extreme durability
  • 2-jaw clutch ensures progressive torque increase for high torque bolt disassembly applications with minimal vibration
  • 360° rotatable side handle offers excellent grip for all applications
