Technical Specifications
Torque
Max working torque fwd :- 68 Nm
Max torque reverse :- 102 Nm
Min working torque fwd :- 7 Nm
Torque limited :- No
Air information
Air consumption at load :- 4.7 l/s
Air inlet thread size (in) :- 1/4
Max dynamic air working pressure :- 6.3 bar
Min hose diam (16 ft hose length) :- 0.38 in
Min hose diam (5 m hose length) :- 10 mm
Noise & vibrations
Sound Power :- 98 dB(A)
Sound Pressure :- 87 dB(A)
Uncertainty vibration-K :- 3.3 m/s²
Vibration (m/s²) :- 4.7
Speed
Free Speed :- 11000 rpm
Size & Weight
Length (L) :- 146 mm
Power weight ratio :- 85 Nm/kg
Weight :- 1.2 kg
Design & Functions
Blow per minute :- 1620
Body :- Aluminum
Clutch housing :- Aluminum
Clutch lubrication type :- Oil bath
Handle type :- Pistol
Impact mecanism :- Rocking dog
Main Material type :- Aluminium
Output drive size (in) :- 3/8
Output drive type :- Sq
Output retainer type :- Friction ring
Starting system :- Trigger
Benefits
- The metal motor housing with rocking dog impact mechanism guarantees smooth operation and a high durability
- A compact tool allowing easy access in tight applications
- A comfortable tool with built-in power regulator and ergonomic handle
