Technical Specifications
Torque
Max torque in forward :- 7.5 Nm
Min torque in forward :- 1 Nm
Torque Control System :- Shut-off-pneumatic valve
Design & Functions
Adjustment :- Rotative ring
Body :- Composite
Clutch housing :- Steel
Clutch Type :- Ball clutch
Handle type :- Pistol
Main Material type :- Composite
Output drive size (in) :- 1/4
Output drive type :- Hex
Output retainer type :- Quick change
Reversible :- Yes
Starting system :- Trigger
Speed
Free Speed :- 1000 rpm
Air consumption at free speed :- 10 l/s
Air information
Air inlet thread size (in) :- 1/4
Air inlet thread type :- NPT
Max dynamic air working pressure :- 6.3 bar
Min hose diam (16 ft hose length) :- 0.38 in
Min hose diam (5 m hose length) :- 10 mm
Noise & vibrations
Sound Power :- 91 dB(A)
Sound Pressure :- 80 dB(A)
Vibration (m/s²) :- <2.5
Size & Weight
Height (H) :- 175 mm
Length (L) :- 235 mm
Weight :- 1.1 kg
Benefits
- Accurate and durable shut-off clutch for various fastening
- Keyless quick torque setting
- Light composite body for better ergonomic handling
- Progressive trigger & reverse on top
- 3 air inlets for versatile access
