Technical Specifications
Design & Functions
Autobalancer :- Yes
Circular Abrasive Pad Size (in) :- 7
Circular Abrasive Pad Size (mm) :- 180
Exhaust :- 360°
Governor type :- Ball
Main Material type :- Aluminium
Output Spindle Thread :- 5/8-11 UNC
Pad holes number :- 0
Rotative inlet :- No
Spindle lock :- Yes
Starting system :- Safety lever
Noise & vibrations
Sound Power :- 98 dB(A)
Sound Pressure :- 87 dB(A)
Air information
Air consumption at load :- 36 l/s
Air inlet thread size (in) :- 1/2
Air inlet thread type :- BSP
Max dynamic air working pressure :- 6.3 bar
Min hose diam (16 ft hose length) :- 0.63 in
Min hose diam (5 m hose length) :- 10 mm
Power
Max power :- 2100 W
Size & Weight
Length (L) :- 340 mm
Weight :- 2.3 kg
Speed
Free Speed :- 8500 rpm
Air consumption at free speed :- 17 l/s
Overspeed shut-off :- No
Benefits
- Highly durable spiral bevel gear reduces vibration and torque transmission stress, resulting in a 2,000 h maintenance interval
- Double streamlined safety lever facilitates single hand engagement and helps reduce risk of accidental start up
- Ergonomic, multi-position (360°), anti-vibration side handle to keep the operator’s wrist straight and comfortable
- 360° adjustable air exhaust with integrated muffler for a noise level limited to 84 dB(A)
- Debris magnet to collect debris and extend super durable spiral bevel gear
