Description
- Model :
77H30B106 / 77H50B106 - Rated Power (hp) :
1.5 / 1.5 - Rated Power hp (kW) :
1.1 / 1.1 - Max Free Speed (rpm) :
3000 / 5000 - Exhaust :
Side / Side - Output Thread :
(5/8 in.- 11 Thread) / (5/8 in.- 11 Thread) - Weight (lbs) :
7.31 / 7.31 - Weight (kg) :
3.3 / 3.3 - Length (in) :
17.69 / 17.69 - Length (mm) :
449 / 449 - Vibration m/s2 (uncertainty K) :
5.9 (uncertainty: 2.1) / 7.8 (uncertainty: 2.7) - Sound Pressure/ Power dBA :
(85.2 / 98.2) / (94.4 / 107.4) - Min Hose Size (in) :
(1/2) / (1/2) - Min Hose Size (mm) :
13 / 13 - Air Inlet (in) :
(3/8 NPT) / (3/8 NPT) - Air Consumption @ Load (cfm) :
29 / 9 - Air Consumption @ Load (L/min) :
822 / 255
