Features
- Closed-loop transducer delivers a torque accuracy of +/- 5%
- Enhanced quantitative feedback – displaying the actual measured torque or angle result
- Integrated gearbox provides premium quality and accuracy
- Brushless Motor offers maximum durability
- Intuitive qualitative feedback using green, red, and yellow indicators
- 360° adjustable handle, with 6 mm threaded port for eye hooks or other tethering points, provides operator comfort, flexibility and safety options
- Standard or custom reaction arms available to match your application needs
- Optional wireless communication for process control with I/O and data collections (USB connection standard)
- Multiple Programming Methods: Wirelessly Through INSIGHTqcx Controller, Through USB with INSIGHTqcx Controller, Insight Connect Android App and ICS Software, Through On-Board Tool Display/Key
- Mobile application for Insight Connect Android APP
|
Model |
Item |
Recommended Target Torque (Nm) |
Recommended Target Torque (ft-lb) |
RPM |
Weight (kg) |
Length (mm) |
Width (mm) |
Drive Size (in) |
Voltage |
Communication |
|---|---|---|---|---|---|---|---|---|---|---|
|
QXC2PT200NPS12 |
Bare Tool |
40 – 200 |
30 – 148 |
45 |
3.62 |
373 |
56 |
3/4 |
20V |
Via USB Cable Only |
|
QXC2PT500NPS12 |
Bare Tool |
100 – 500 |
74 – 369 |
18 |
3.62 |
373 |
56 |
3/4 |
20V |
Via USB Cable Only |
|
QXC2PT1000NPS12 |
Bare Tool |
200 – 1000 |
148 – 738 |
9 |
5.44 |
419 |
80 |
3/4 |
20V |
Via USB Cable Only |
|
QXC2PT1350NPS16 |
Bare Tool |
270 – 1350 |
200 – 996 |
7 |
5.44 |
419 |
80 |
1 |
20V |
Via USB Cable Only |
|
QXC2PT2000NPS16 |
Bare Tool |
400 – 2000 |
295 – 1475 |
5 |
6.8 |
452 |
80 |
1 |
20V |
Via USB Cable Only |
|
QXX2PT200NPS12 |
Bare Tool |
40 – 200 |
30 – 148 |
45 |
3.62 |
373 |
56 |
3/4 |
20V |
Wireless Enabled |
|
QXX2PT500NPS12 |
Bare Tool |
100 – 500 |
74 – 369 |
18 |
3.62 |
373 |
56 |
3/4 |
20V |
Wireless Enabled |
|
QXX2PT1000NPS12 |
Bare Tool |
200 – 1000 |
148 – 738 |
9 |
5.44 |
419 |
80 |
3/4 |
20V |
Wireless Enabled |
|
QXX2PT1350NPS16 |
Bare Tool |
270 – 1350 |
200 – 996 |
7 |
5.44 |
419 |
80 |
1 |
20V |
Wireless Enabled |
|
QXX2PT2000NPS16 |
Bare Tool |
400 – 2000 |
295 – 1475 |
5 |
6.8 |
452 |
80 |
1 |
20V |
Wireless Enabled |
|
QXC2P200PS12K2-EU |
Kit |
40 – 200 |
30 – 148 |
45 |
3.62 |
373 |
56 |
3/4 |
20V |
Via USB Cable Only |
|
QXC2P500PS12K2-EU |
Kit |
100 – 500 |
74 – 369 |
18 |
3.62 |
373 |
56 |
3/4 |
20V |
Via USB Cable Only |
|
QXC2P1000PS12K2-EU |
Kit |
200 – 1000 |
148 – 738 |
9 |
5.44 |
419 |
80 |
3/4 |
20V |
Via USB Cable Only |
|
QXC2P1350PS16K2-EU |
Kit |
270 – 1350 |
200 – 996 |
7 |
5.44 |
419 |
80 |
1 |
20V |
Via USB Cable Only |
|
QXC2P2000PS16K2-EU |
Kit |
40 – 200 |
295 – 1475 |
5 |
6.8 |
452 |
80 |
1 |
20V |
Via USB Cable Only |
