Makita Cordless Impact Driver DTD172

18V LXT BL Brushless Cordless Wood/Bolt/T-Mode 180 N·m Impact Driver

Tool head slimmer than DTD171 enables easy screwdriving in tight corners or confined spaces
Slimmer tool body due to smaller controller circuit
Light mode enables to use DTD172 as a handy light on dark job sites
Anti-bit wobbling structure; Two ball bearings are used to securely hold the anvil for reduced bit wobbling
One-touch bit installation; Reduced resistance allows for easier bit installation; Designed to hold the bit more securely
Twin LED lights on both sides illuminate the work area for increased visibility
Wood/Bolt/T-Mode (1, 2)/Max/Hard/Medium/Soft Mode for Multiple Applications
Redesigned mode selection switch for one-handed mode selection
Rigid anvil retention for reduced bit wobbling
Power selection switch provides the user with precise fastening control for a wide range of applications
BL motor delivers 3,600 max RPM and 180 N·m of max torque
BL motor is electronically controlled to optimize battery energy use for longer run time per charge
BL motor eliminates carbon brushes, enabling the BL motor to run cooler and more efficiently for longer life
BL motor efficiently uses energy to match torque and RPM to the changing demands of the application
Lightweight for reduced operator fatigue
Convenient one-touch 6.35 mm (1/4″) hex chuck for quick bit changes (for some countries only)
Soft grip provides increased comfort on the job

Description

Capacity :
Machine Screw: M4 – M8 (5/32 – 5/16″) Standard Bolt: M5 – M16 (3/16 – 5/8″) High Strength Bolt: M5 – M14 (3/16 – 9/16″) Coarse thread (in length): 22 – 125 mm (7/8 – 4-7/8″) Wood (Auger Bit): 24 mm (15/16″)
Hex Shank :
6.35 mm (1/4″)
No Load Speed (RPM):
Max / Hard / Mid / Soft / Wood / Bolt / T (1) / T (2) mode:: 0 – 3,600 / 3,200 / 2,100 / 1,100 / 1,800 / 3,600 / 2,900 / 3,600
Impacts Per Minute (IPM):
Max / Hard / Mid / Soft / Wood / Bolt / T (1) / T (2) mode:: 0 – 3,800 / 3,600 / 2,600 / 1,100 / 3,800 / 3,800 / N/A / 2,600
Max Fastening Torque:
180 N·m (1,590 in.lbs.)
Fastening Torque :
Hard / Mid / Soft: 170 / 50 / 20 N·m (1,510 / 440 / 180 in.lbs.)
Max Output :
290 W
Vibration Level :
Impact tightening of fasteners of the maximum capacity of the tool: 13.5 m/s²
Vibration K Factor :
Impact tightening of fasteners of the maximum capacity of the tool: 1.5 m/s²
Sound Pressure Level :
97 dB(A)
Sound Power Level :
108 dB(A)
Noise K Factor :
3 dB(A)
Dimensions (L x W x H) :
w/o Battery: 114 x 81 x 189 mm (4-1/2 x 3-3/16 x 7-7/16″) w/ BL1815N / BL1820B: 114 x 81 x 218 mm (4-1/2 x 3-3/16 x 8-5/8″) w/ BL1830B / BL1840B / BL1850B / BL1860B: 114 x 81 x 236 mm (4-1/2 x 3-3/16 x 9-1/4″)
Hole Saw Diameter : 38 mm (1-1/2″)
Shank/Drive : Hex Shank 6.35 mm (1/4″)
Net weight : 1.2 – 1.5 kg (2.6 – 3.3 lbs.)
https://makita.in/wp-content/uploads/2022/04/DTD172_view.pdf
