Technical Specifications
Size & Weight
Height (H) :- 59 mm
Length (L) :- 243 mm
Weight :- 0.7 kg
Power
Max power :- 375 W
Air information
Air consumption at load :- 10 l/s
Air inlet thread size (in) :- 1/4
Air inlet thread type :- NPT
Max dynamic air working pressure :- 6.3 bar
Min hose diam (16 ft hose length) :- 0.31 in
Min hose diam (5 m hose length) :- 8 mm
Speed
Free Speed :- 20000 rpm
Air consumption at free speed :- 6.5 l/s
Overspeed shut-off :- No
Design & Functions
Autobalancer :- No
Circular Abrasive Pad Size (in) :- 3
Circular Abrasive Pad Size (mm) :- 75
Governor type :- Ball
Main Material type :- Aluminium, Composite over-sleeve
Output Spindle Thread :- 1/4-20 UNC
Rotative inlet :- No
Spindle lock :- No
Starting system :- Safety lever
Noise & vibrations
Sound Power :- 88 dB(A)
Sound Pressure :- 77 dB(A)
Uncertainty vibration-K :- 1.3 m/s²
Vibration :- 2.8 m/s²
General
Energy type :- Pneumatic
Family :- Sanders
Subfamily :- Angle Sanders
Benefits
- Highly durable bevel gear allow maintenance intervals up to 2000 hours
- Compact body for confined space applications
- Insulating composite over housing ensure operatort comfort
- Streamlined safety lever
- Rear exhaust
